Borri RTB range of Industrial Thyristor Controlled 3-Phase Battery Chargers are designed and built for the harshest conditions and to provide high-reliability power supply and battery charging capability. Using a powerful microprocessor to control all the functions provides reliable operations with ease of setting and communication.

Built with a rugged thyristor-controlled rectifier bridge suitable for charging nickel-cadmium or lead acid batteries while simultaneously supplying DC loads. It can also be used without batteries as a direct power supply.

Main features

- Proven microprocessor control.

- Large LCD panel with a mimic panel and history.

- Wide selection of alarms, indications, and measurements.

- Electronic battery and charger output current limit.

- Rugged thyristor bridge with an isolation transformer.

- Communication ports and potential free contacts.

- 4-level battery charging, including manual charge.

- High MTBF and low MTTR.

- 20 programmable alarm and status LEDs.

- Operates with Nickel-cadmium (vented/ gas recombination) and Lead acid batteries (vented/ gas recombination).

- Advanced Battery Management.

- Flexible in-built features.

- Operation without battery (Rectifier).

- Highly customizable.

- Easy maintenance and serviceability.

The RTB Compact is designed to cover the lower range of industrial chargers, but still offers all the functions and controls with a Borri microprocessor controller, providing reliable operations with ease of settings and communication.

Built with a rugged thyristor-controlled rectifier bridge suitable for charging nickel-cadmium or lead acid batteries while simultaneously supplying DC loads.


Main features

- Proven microprocessor control.

- Large LCD panel with mia mic panel and history.

- Wide selection of alarms, indications, and measurements.

- Electronic battery and charger output current limit.

- Rugged thyristor bridge with an isolation transformer.

- Communication ports and potential free contacts.

- 4-level battery charging, including optional manual charge.

- High MTBF and low MTTR.

- Operates with Nickel-cadmium (vented/ gas recombination) and Lead acid batteries (vented/ gas recombination).

- 10 programmable alarm and status LEDs.

- Advanced Battery Management.

- Flexible in-built features.

- Operation without a battery (rectifier).

- Easy maintenance and serviceability.

Borri Modular DC Uninterruptible Power System has been designed for industrial applications from oil & gas, power generation, utilities, water treatment, desalination, to transport, telecom, chemical industries, and industrial process control.

UMB has been designed and developed to withstand harsh environments and operating conditions of Industrial applications with state-of-the-art technology, providing flexible, reliable, and customized system solutions with very low MTTR.

Main features

- LCD display and data interface for monitoring.

- Single, N+1 and N+N configurations.

- Scalability for future power growth.

- Compact 19” design and customized engineering.

Compact, heavy-duty Rectifier Battery Charger with full galvanic insulation. Designed to supply auxiliary loads, Switchgears and Protection Relays of Electrical Substations in the Utilities applications.

• Input Rectifier transformer for AC/DC galvanic separation
• Standard configuration for cost-effective, short lead time solutions
• Reduced footprint of the cabinet for easy installation
• 16-bit microcontroller control, digital control panel with history of alarms, full set of communications options

Benefits

- The product is available in a well defined configuration, immediately usable for a wide range of applications. Fast delivery time for standard configuration is granted.

- The product layout, allow to the final user the possibility of an easy and fast maintenance. All the components are well disposed inside the unit, and the panels can be installed against the walls.

- The product can be easily added to any existing project, thanks to the experience and knowhow of Borri engineering team. The customer will be supported from our technical department, along the entire cycle of the project.

- The product include an advanced user interface, and powerful tools for troubleshooting and monitoring. All the basic and advanced operations, will be done using simply the user interface of front panel.

Borri AC Industrial 1-Ph Inverter IMB is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup solutions.

Borri’s IMB is a heavy-duty AC Industrial Inverter with output galvanic isolation. The Inverter design ensures very high reliability, safe operations, full front access for easy maintenance and a very low mean time to repair (MTTR), achieving the highest possible availability.

The design flexibility allows it to meet almost any customer specification. IMB Inverter is an industrial solution delivering reliability, availability and maintainability in almost any environmental conditions.



Main Features

- Large LCD panel with a mimic diagram and history.

- Wide selection of alarms, indications and measurements.

- Built-in inverter transformer.

- PWM IGBT Inverter Bridge.

- Built-in manual bypass.

- Flexible in-built features.

- Highly customizable.

- Easy maintenance and serviceability.

Borri AC Industrial 3-Ph Inverter ITB is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup solutions.

Borri’s ITB is a heavy-duty AC Industrial Inverter with output galvanic isolation. The Inverter design ensures very high reliability, safe operations, full front access for easy maintenance and a very low mean time to repair (MTTR), achieving the highest possible availability.

The design flexibility allows it to meet almost any customer specification. ITB Inverter is an industrial solution delivering reliability, availability and maintainability in almost any environmental conditions.

Main Features

- Large LCD panel with mimic diagram and history.

- Wide selection of alarms, indications and measurements.

- Built-in inverter transformer.

- PWM IGBT Inverter Bridge.

- Built-in manual bypass.

- Flexible in-built features.

- Highly customizable.

- Easy maintenance and serviceability.

Borri AC Industrial 1-Ph Uninterruptible Power System E2001 is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup solutions.

Borri’s E2001 is a heavy-duty on-line double conversion AC Industrial UPS with full galvanic isolation. The UPS design ensures very high reliability, safe operations and a very low mean time to repair (MTTR), achieving the highest possible availability. The design flexibility allows it to meet almost any customer specification.

E2001 UPS is a cost-effective solution delivering reliability, availability and maintainability in almost
any environmental conditions.


Main Features

- Rugged rectifier thyristor bridge with input isolation transformer.

- Large LCD panel with mimic diagram and history.

- Wide selection of alarms, indications and measurements.

- Built-in inverter transformer.

- PWM IGBT Inverter Bridge.

- Built-in manual bypass.

- Advanced battery management.

- Flexible in-built features.

- Highly customizable.

- Easy maintenance and serviceability.

The Borri Industrial 1 -Phase UPS E2001 Compact is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup in a compact standardised solution.

Borri’s E2001 Compact is a heavy-duty on-line double conversion AC Industrial UPS with full galvanic isolation. The UPS design ensures very high reliability and safe operations; its internal constructions allows for front and easy maintenance.

The design flexibility and the wide range of configurable options allows it to meet almost any customer specification.

E2001 Compact  Industrial 1-Phase UPS is a cost-effective solution delivering reliability, availability and maintainability in almost any environmental conditions.


Main Features

- Rugged rectifier thyristor bridge with input isolation transformer.

- Large LCD panel with mimic diagram and history.

- Wide selection of alarms, indications and measurements.

- Built-in isolation transformer.

- PWM IGBT Inverter Bridge.

- Built-in manual bypass.

- Advanced battery management.

- Flexible in-built features.

- Widely configurable.

- Easy maintenance and serviceability.

Borri AC Industrial 3-Ph Uninterruptible Power System E3001 is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup solutions.

Borri’s E3001 is a heavy-duty on-line double conversion AC Industrial UPS with full galvanic isolation. The UPS design ensures very high reliability, safe operations and a very low mean time to repair (MTTR), achieving the highest possible availability.

The design flexibility allows it to meet almost any customer specification. E3001 UPS is a cost-effective solution delivering reliability, availability and maintainability in almost
any environmental conditions.

Main features

• Rugged rectifier thyristor bridge with input isolation transformer.
• Large LCD panel with a mimic diagram and history.
• Wide selection of alarms, indications and measurements.
• Built-in inverter transformer.
• PWM IGBT Inverter Bridge.
• Built-in manual bypass.
• Advanced battery management.
• Flexible in-built features.
• Highly customizable.
• Easy maintenance and serviceability.

The Borri Industrial 3 Phase UPS E3001 Compact is designed and manufactured to withstand harsh environment and operating conditions of industrial applications with state-of-the-art technology, providing reliable and customizable AC power backup in a compact standardised solution.

Borri’s E3001 Compact is a heavy-duty on-line double conversion AC Industrial UPS with full galvanic isolation. The UPS design ensures very high reliability and safe operations; its internal constructions allows for front and easy maintenance.

The design flexibility and the wide range of configurable options allows it to meet almost any customer specification.

E3001 Compact  Industrial 3-Phase UPS is a cost-effective solution delivering reliability, availability and maintainability in almost any environmental conditions.


Main features

• Rugged rectifier thyristor bridge with input isolation transformer.
• Large LCD panel with a mimic diagram and history.
• Wide selection of alarms, indications and measurements.
• Built-in isolation transformer.
• PWM IGBT Inverter Bridge.
• Built-in manual bypass.
• Advanced battery management.
• Flexible in-built features.
• Widely configurable.
• Easy maintenance and serviceability.
